Shelly Pro Dimmer 0/1-10V PM lighting controller
Shelly Pro Dimmer 0/1-10V PM is an advanced controller that allows you to control the light and monitor energy consumption in real time. With support for 0-10V and 1-10V standards, the device works with a variety of light sources, including LEDs, halogens and transformers. Users can use schedules that automatically adjust brightness according to the time of day, and synchronize lighting with sunrise and sunset times. Integration with popular assistants such as Amazon Alexa and Google Home allows users to conveniently control the lighting with voice commands, enhancing user experience and saving energy. The product is designed for DIN rail mounting.
Automation and schedules
One of the most important advantages of the Shelly Pro Dimmer is the ability to create advanced schedules that automatically adjust brightness depending on the time of day. With this feature, users can synchronize lighting with the natural cycle of the day, which promotes energy savings and increases comfort. In Night mode, the device automatically reduces the brightness of the lighting in the evening hours, which not only helps create a pleasant atmosphere, but also saves energy.
Various operation options
The Shelly Pro Dimmer controller uses Wi-Fi and Bluetooth protocols, and works with popular smart assistants such as Amazon Alexa, Google Assistant and Samsung SmartThings. This allows you to conveniently control your lighting with voice commands. A mobile app is also available, allowing you to remotely manage the controller s functions from anywhere. From it, you can set schedules, create various lighting scenarios and monitor energy consumption.
Precise energy monitoring
The built-in energy monitoring system provides detailed information about the energy consumption of connected light sources. Users can check the consumption in kWh units in real time, which allows them to identify inefficient devices and makes it easier to take energy-saving measures. As a result, electricity bills can be reduced.
Convenience and safety of use
The Shelly Pro Dimmer offers various modes of operation, including the ability to operate single or double dimming via physical buttons. This allows you to use existing switches. As a result, installation of the device is quick and convenient, and users can use the interface they are accustomed to. The controller also provides protection against overload, overvoltage and overheating, increasing safety and reliability.
Complete control in your hands
Shelly s product offers advanced features such as scripts, webhooks and local actions that allow you to customize its operation. This allows you to create unique automation scenarios that perfectly fit your individual lifestyle. Now the light can automatically turn on when someone enters the room, and the brightness level can change depending on the time of day. The Shelly Pro Dimmer is an intelligent lighting command center, adapting to changing conditions and preferences.

GENERAL
Manufacturer
Shelly
Manufacturer code
ProDim0/1-10VPM

PHYSICAL PARAMETERS
Dimensions
94 x 19 x 69 mm / 3.70x0.75x2.71 inches
Weight
70 g / 2.5 oz
Maximum terminal torque
0.4 Nm / 3.54 lbf in
Cross section of wires
0.5-2.5 mm2 / 20 to 14 AWG (green connectors), 0.5-1.5 mm2 / 20 to 16 AWG (blue connectors)
Wire stripping length
6-7 mm / 0.24-0.28 in (green connectors), 5-6 mm / 0.20-0.24 in (blue connectors)
Mounting
DIN
Housing material
Plastic
Housing color
Blue
Connector color
Green and blue

ENVIRONMENTAL PARAMETERS
Operating temperature
-20°C to 40°C / -5°F to 105°F
Humidity
30% to 70% RH
Max altitude
2000 m / 6562 ft

ELECTRICAL PARAMETERS
Power supply
110-240 V~
Power consumption
Neutral wire
Not required
Voltage control type 0-10V / 1-10V
Current source
External protection
16 A, breaking characteristics B or C, breaking current 6 kA, energy limitation class 3

CIRCUIT OUTPUT PARAMETERS
Maximum switching voltage
240 V~
Maximum switching current
16 A

SENSORS, METERS
Voltmeter (AC)
Yes
Ammeter (AC)
Yes
Power and energy meters
Active and apparent power, active and apparent energy, power factor, active and reactive fundamental energy
Measurement data memory
No
Internal temperature sensor
Yes

WI-FI
Protocol
802.11 b/g/n
RF band
2412 - 2472 MHz
Maximum power R
Range
Up to 30 m / 100 ft indoors and up to 50 m / 160 ft outdoors (depending on local conditions)

BLUETOOTH
Protocol
4.2
RF band
2402 - 2480 MHz
Maximum RF power
Range
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (depending on local conditions)

MICROCONTROLLER
CPU
ESP32-D0WDQ6
Clock frequency
40 MHz
Flash memory
8 MB

SOFTWARE FEATURES
Schedules
Support for up to 20 schedules
Webhooks (URL shares)
Up to 20 webhooks, with support for 5 URLs per webhook
Scripts
Yes
MQTT
Yes
Advanced scheduling
Yes
KVS (Key-Value Storage)
Yes

---
