HPE Networking Instant On AP27 (EU) Dual Radio 2x2 Wi-Fi 6 Outdoor AP Bundle with PS (Includes 30W PoE midspan injector
HPE Networking Instant On AP27 (EU) Dual Radio 2x2 Wi-Fi 6 Outdoor AP Bundle with PS (Includes 30W PoE midspan injector
7966 Kč
6583 Kč bez DPH
Dostupnost: Skladem v eshopu
Part no.: S1T42A
Kód produktu: 113687909
Výrobce: Hewlett Packard Enterprise
 |
Potřebujete více informací?
484800850 po-pá 8:00-16:30 |
Popis produktu
Technical Specifications
AP21
AP22
AP22D
AP25
AP27
AP32
Radios
Dual-Band 802.11ax 2x2 5Ghz/2.4Ghz
MIMO
Dual-band 802.11ax 2x2 5Ghz/2.4GhZ MIMO
Dual-band 802.11ax 2x2 5Ghz/2.4Ghz MIMO
Dual-Band 802.11ax 4x4 5Ghz MU-MIMO
2x2 2.4Ghz MU-MIMO
Dual-Band 802.11ax
2x2 5GHz MU-MIMO
2x2 2.4GHz MIMO
Tri-band 802.11ax
2x2 6Ghz/5Ghz/ 2.4Ghz MU-MIMO
Maximum Bandwidth Support
20/40/ 80MHz
20/40/ 80MHz
20/40/ 80MHz
20/40/80/ 160MHz
20/40/ 80MHz
20/40/80/ 160MHz
Maximum Data Rate *
1.2Gbps (5Ghz) 300Mbps (2.4Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
900 Mbps (aggregate switch capacity)
4.8Gbps (5Ghz) 574 Mbps (2.4Ghz)
1.2Gbps (5GHz)
574 Mbps (2.4GHz)
2.4Gbps (6Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
Interfaces
1 GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
1 GbE BaseT Uplink DC Power Connector Bluetooth Low Energy (BLE)
LED status Indicators Reset/LED control button
Kensington security slott
1x 2.5GbE BaseT PoE Class 4/6 Uplink
2x 1GbE BaseT PoE Class 3 Downlink
2x 1GbE BaseT Downlink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
1GbE Base-T uplink port
LED status indicators
Reset button
Kensington security slot
1x 2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
Recommended number of devices
50
75
75
100+
75
75
Antennas
Down-tilt Dual Omni- directional
2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MIMO
Dual Semi-directional 2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MU-MIMO
Dual omni-directional
2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MU-MIMO
Antenna Gain
1.7dBi in 2.4GHz
4.8dBi in 5GHz
4.9dBi in 2.4GHz
5.7dBi in. 5GHz
5.2dBi in 2.4GHz
5.4dBi in 5GHz
4.2dBi in 2.4GHz
7.5dBi in 5GHz
3.2dBi in 2.4GHz
5.4dBi in 5GHz
2.8dBi in 2.4GHz
4.5dBi in 5GHz and 6GHz
Maximum Transmit Power
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dBMIMO gain)
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +20dBm (+17dBm per chain, 3dB MIMO gain)
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +20dBm (+17dBm per chain, 3dB MIMO gain)
5GHz band: +24dBm (+18dBm per chain, 6dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
5GHz band: +25dBm (+22dBm per chain, 3dB MIMO gain)
2.4GHz band:
+25dBm (+22dBm per chain, 3dB MIMO gain)
5GHz & 6GHz band:
+21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
Power Options
PoE: 802.3at (class 4) or 802.3af (class 3)
DC power (12V)
POE: 802.3af (class 3) DC power (12V)
PoE: 802.3bt (class 6) Full functionality or 802.3at (class 4) limited functionality
DC power (48V)
POE: 802.3at (class 4) DC power (12V)
PoE: 802.3af (class 4)
PoE: 802.3bt (class 6) or 802.3at (class 4)
DC power (12V)
Power Over Ethernet
PoE In: 802.3af/802.3at
POE In: 802.3af
POE In: 802.3at/802.3bt POE Out: 2x 15W PoE (802.3af)
POE In: 802.3at
PoE In: 802.3at
POE In: 802.3at
Max Power Consumption
PoE In: 802.3at 10.9W (DC)
10.1W (PoE)
8.8W (DC)
51W (PoE)
50W (DC)
20.1W (PoE)
15.9W (DC)
14.6W (PoE)
12.9W (PoE)
11.0W (DC)
Physical Specifications
145mm x 145mm x 51mm
Weight: 255g
160mm x 160mm x 37mm
Weight: 500g
86mm x 47mm x 150mm Weight: 360g
200mm x 200mm x 45mm
Weight: 775g
180 mm x 232 mm x 120 mm
Weight: 1170g
160mm (W) x 160mm (D) x 39mm (H) Weight: 520g
Mounting
Ceiling/Wall mount clip
Ceiling/Wall mount clip
Gang wall-box mount kit Desk mount kit
Ceiling/Wall mount clip
Ceiling/wall mount bracket
Ceiling/Wall mount clip
Operating Temperature
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
-40° C to +65° C (-40° F to
+149° F)
0° C to +40° C (+32° F to
+104° F)
Reliability (years)
106
91
88
76
248
62
HPE Networking Instant On Wi-Fi 6 Access Points
High-speed Wi-Fi designed with small business in mind
The HPE Networking Instant On Wi-Fi 6 Access Points portfolio is designed to meet the increasing volume of connected devices that face small businesses. Our range of Wi-Fi Certified 6 access points delivers superior performance, coverage, and speed at a competitive price that is perfect for small and growing businesses.
The HPE Networking Instant On Wi-Fi 6 Access Points family has the right access point to fit your business needs. From cost-effective single room streaming to conference room collaboration to exhibition hall environments, our wireless solutions make your network accessible and efficient.
From IoT and point-of-sale devices to hundreds of guests connecting to your network, you need hardware that can keep up with changing daily demands without intervention. HPE Networking Instant On Wi-Fi 6 access points are designed to host from 30 to over 150 simultaneous connections. Our smart cloud management features are simple to use and quick to set up, with many enterprise-class features enabled by default.
The Wi-Fi 6 family features MU-MIMO, OFDMA, and up to 4 spatial streams to keep users and devices connected while the built-in TPM, WPA3, and wireless access control lists keep your network secure. Setting up guest and employee networks is just a few taps away on the HPE Networking Instant On mobile app. The Smart Mesh and range-boosting features in the mobile app combined with automatic beamforming provide coverage to those hard-to-reach areas of your business.
We know the critical role that Wi-Fi plays in business today - no one can afford downtime. The HPE Networking Instant On Wi-Fi 6 Access Points family is designed for rapid deployment and simplified management. Be it mounting hardware, remote device management or access to the latest business-grade software, the HPE Networking Instant On Wi-Fi 6 Access Points hardware makes your life easier.
Product Line-Up
The HPE Networking Instant On Wi-Fi 6 family has the right access point to fit your business needs. From cost-effective single room streaming to conference room collaboration to exhibition hall environments, our wireless solutions make your network accessible and efficient.
Take your business outdoors with the HPE Networking Instant On Access Points AP27. This fast outdoor Wi-Fi 6 AP is IP67 rated, keeping you connected through hot summers, frigid winters, rain, sleet, and snow. Able to withstand temperatures from temperatures from -40°F to 149°F, you can confidently connect up to 75 devices over Wi-Fi 6 to extend coverage to parking lots, outdoor workspaces, and hotel pools.
Key Features
Ultra-fast 802.11ax
Available 2.5 Gigabit
Wi-Fi CERTIFIED 6TM (Wi-Fi 6)
MU-MIMO performance
Smart Mesh Wi-Fi...
Popis produktu
HPE Networking Instant On AP27 (EU) Dual Radio 2x2 Wi-Fi 6 Outdoor AP Bundle with PS (Includes 30W PoE midspan injector with EU Power Cord)Technical Specifications
AP21
AP22
AP22D
AP25
AP27
AP32
Radios
Dual-Band 802.11ax 2x2 5Ghz/2.4Ghz
MIMO
Dual-band 802.11ax 2x2 5Ghz/2.4GhZ MIMO
Dual-band 802.11ax 2x2 5Ghz/2.4Ghz MIMO
Dual-Band 802.11ax 4x4 5Ghz MU-MIMO
2x2 2.4Ghz MU-MIMO
Dual-Band 802.11ax
2x2 5GHz MU-MIMO
2x2 2.4GHz MIMO
Tri-band 802.11ax
2x2 6Ghz/5Ghz/ 2.4Ghz MU-MIMO
Maximum Bandwidth Support
20/40/ 80MHz
20/40/ 80MHz
20/40/ 80MHz
20/40/80/ 160MHz
20/40/ 80MHz
20/40/80/ 160MHz
Maximum Data Rate *
1.2Gbps (5Ghz) 300Mbps (2.4Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
900 Mbps (aggregate switch capacity)
4.8Gbps (5Ghz) 574 Mbps (2.4Ghz)
1.2Gbps (5GHz)
574 Mbps (2.4GHz)
2.4Gbps (6Ghz)
1.2Gbps (5Ghz) 574 Mbps (2.4Ghz)
Interfaces
1 GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
1 GbE BaseT Uplink DC Power Connector Bluetooth Low Energy (BLE)
LED status Indicators Reset/LED control button
Kensington security slott
1x 2.5GbE BaseT PoE Class 4/6 Uplink
2x 1GbE BaseT PoE Class 3 Downlink
2x 1GbE BaseT Downlink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
1GbE Base-T uplink port
LED status indicators
Reset button
Kensington security slot
1x 2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button
Kensington security slot
Recommended number of devices
50
75
75
100+
75
75
Antennas
Down-tilt Dual Omni- directional
2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MIMO
Dual Semi-directional 2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MU-MIMO
Dual omni-directional
2x2 MIMO
Down-tilt Dual Omni- directional
2x2 MU-MIMO
Antenna Gain
1.7dBi in 2.4GHz
4.8dBi in 5GHz
4.9dBi in 2.4GHz
5.7dBi in. 5GHz
5.2dBi in 2.4GHz
5.4dBi in 5GHz
4.2dBi in 2.4GHz
7.5dBi in 5GHz
3.2dBi in 2.4GHz
5.4dBi in 5GHz
2.8dBi in 2.4GHz
4.5dBi in 5GHz and 6GHz
Maximum Transmit Power
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dBMIMO gain)
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +20dBm (+17dBm per chain, 3dB MIMO gain)
5GHz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +20dBm (+17dBm per chain, 3dB MIMO gain)
5GHz band: +24dBm (+18dBm per chain, 6dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
5GHz band: +25dBm (+22dBm per chain, 3dB MIMO gain)
2.4GHz band:
+25dBm (+22dBm per chain, 3dB MIMO gain)
5GHz & 6GHz band:
+21dBm (+18dBm per chain, 3dB MIMO gain)
2.4Ghz band: +21dBm (+18dBm per chain, 3dB MIMO gain)
Power Options
PoE: 802.3at (class 4) or 802.3af (class 3)
DC power (12V)
POE: 802.3af (class 3) DC power (12V)
PoE: 802.3bt (class 6) Full functionality or 802.3at (class 4) limited functionality
DC power (48V)
POE: 802.3at (class 4) DC power (12V)
PoE: 802.3af (class 4)
PoE: 802.3bt (class 6) or 802.3at (class 4)
DC power (12V)
Power Over Ethernet
PoE In: 802.3af/802.3at
POE In: 802.3af
POE In: 802.3at/802.3bt POE Out: 2x 15W PoE (802.3af)
POE In: 802.3at
PoE In: 802.3at
POE In: 802.3at
Max Power Consumption
PoE In: 802.3at 10.9W (DC)
10.1W (PoE)
8.8W (DC)
51W (PoE)
50W (DC)
20.1W (PoE)
15.9W (DC)
14.6W (PoE)
12.9W (PoE)
11.0W (DC)
Physical Specifications
145mm x 145mm x 51mm
Weight: 255g
160mm x 160mm x 37mm
Weight: 500g
86mm x 47mm x 150mm Weight: 360g
200mm x 200mm x 45mm
Weight: 775g
180 mm x 232 mm x 120 mm
Weight: 1170g
160mm (W) x 160mm (D) x 39mm (H) Weight: 520g
Mounting
Ceiling/Wall mount clip
Ceiling/Wall mount clip
Gang wall-box mount kit Desk mount kit
Ceiling/Wall mount clip
Ceiling/wall mount bracket
Ceiling/Wall mount clip
Operating Temperature
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
0° C to +40° C (+32° F to
+104° F)
-40° C to +65° C (-40° F to
+149° F)
0° C to +40° C (+32° F to
+104° F)
Reliability (years)
106
91
88
76
248
62
HPE Networking Instant On Wi-Fi 6 Access Points
High-speed Wi-Fi designed with small business in mind
The HPE Networking Instant On Wi-Fi 6 Access Points portfolio is designed to meet the increasing volume of connected devices that face small businesses. Our range of Wi-Fi Certified 6 access points delivers superior performance, coverage, and speed at a competitive price that is perfect for small and growing businesses.
The HPE Networking Instant On Wi-Fi 6 Access Points family has the right access point to fit your business needs. From cost-effective single room streaming to conference room collaboration to exhibition hall environments, our wireless solutions make your network accessible and efficient.
From IoT and point-of-sale devices to hundreds of guests connecting to your network, you need hardware that can keep up with changing daily demands without intervention. HPE Networking Instant On Wi-Fi 6 access points are designed to host from 30 to over 150 simultaneous connections. Our smart cloud management features are simple to use and quick to set up, with many enterprise-class features enabled by default.
The Wi-Fi 6 family features MU-MIMO, OFDMA, and up to 4 spatial streams to keep users and devices connected while the built-in TPM, WPA3, and wireless access control lists keep your network secure. Setting up guest and employee networks is just a few taps away on the HPE Networking Instant On mobile app. The Smart Mesh and range-boosting features in the mobile app combined with automatic beamforming provide coverage to those hard-to-reach areas of your business.
We know the critical role that Wi-Fi plays in business today - no one can afford downtime. The HPE Networking Instant On Wi-Fi 6 Access Points family is designed for rapid deployment and simplified management. Be it mounting hardware, remote device management or access to the latest business-grade software, the HPE Networking Instant On Wi-Fi 6 Access Points hardware makes your life easier.
Product Line-Up
The HPE Networking Instant On Wi-Fi 6 family has the right access point to fit your business needs. From cost-effective single room streaming to conference room collaboration to exhibition hall environments, our wireless solutions make your network accessible and efficient.
Take your business outdoors with the HPE Networking Instant On Access Points AP27. This fast outdoor Wi-Fi 6 AP is IP67 rated, keeping you connected through hot summers, frigid winters, rain, sleet, and snow. Able to withstand temperatures from temperatures from -40°F to 149°F, you can confidently connect up to 75 devices over Wi-Fi 6 to extend coverage to parking lots, outdoor workspaces, and hotel pools.
Key Features
Ultra-fast 802.11ax
Available 2.5 Gigabit
Wi-Fi CERTIFIED 6TM (Wi-Fi 6)
MU-MIMO performance
Smart Mesh Wi-Fi...
