Popis produktu

Processor / System Bus

2 x Socket SP3 (LGA 4094)
AMD EPYC™ 7003 Series
AMD EPYC™ 7002 Series
Max TDP : 280W



Generation

E11



Memory

Total Slots :
32 (8-channel per CPU, 16 DIMM per CPU)
Capacity :
Maximum up to 4096GB RDIMM
Memory Type :
Dual Channel DDR4 3200/2933 RDIMM
Dual Channel 3200/2933 LRDIMM
Dual Channel 3200/2933 LR-DIMM 3DS non ECC
Memory Size :
64GB, 32GB, 16GB RDIMM
128GB, 64GB LRDIMM
256GB, 128GB, 64GB LR-DIMM 3DS
* Refer to support page for more information



Graphic Card

Please refer to GPU support list



Expansion Slots

Up to 3 x Expansion slots + 1 x Internal PIKE slot
1 x PCIe Gen4 x16, FHFL (CPU1)
1 x PCIe Gen4 x16, FHFL or OCP3.0 (CPU2)
1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2)

*Installing GPU cards will occupied expansion slots.



Storage

Storage Controller :
4 x SATA3 6Gb/s ports (SATA 6Gb/s & PCIe® Gen4 x4 link)
2 x M.2 connector(2242/2260/2280/22110) both SATA & PCIe mode
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card(Optional)
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card(Optional)
Broadcom MegaRAID 9560-16i (Optional)



Drive Bays

4 x 3.5" hot-swap drive bays (4 x NVMe/SATA/SAS*)
2 x M.2 (support SATA/PCIe M.2) (up to 22110) (CPU2)

*must with PIKE/RAID card



System Fan

8



Auxiliary Storage FDD/CD/DVD

1 x Slim type Optical Drive Bay (optional)



Networking

1 x Quad Port Intel I350-AM4 1G LAN Controller + 1 x Mgmt LAN
or
Option 2
1 x Dual Port Intel X710-AT2 Gigabit 10G LAN Controller + 1 x Mgmt LAN
or
None



Graphic

Aspeed AST2600 with 64MB VRAM



Front I/O Ports

2 x USB 3.2 Gen1 ports
1 x VGA port



Rear I/O Ports

2 x USB 3.2 Gen1 ports
1 x VGA port
1 x RJ-45 Mgmt LAN port
1 x OCP3.0 port (Please remember to insert OCP3.0 Board)



Switch/LED

Front Switch/LED:
1 x Power switch (w/LED)
1 x Reset Switch
1 x Location Switch (w/LED)
1 x HDD Access LED
1 x Message LED LAN 1-4 LED (on NIC Module)

Rear Switch/LED:
1 x Power switch w/LED
1 x Port 80 LED(Q-Code)
1 x Location Switch w/LED
1 x Message LED



OS Support

Please find the latest OS support from  https://www.asus.com/event/Server/OS_support_list/OS.html



Management Solution

On-Board ASMB10-iKVM for KVM-over-IP
ASUS Control Center Enterprise (Optional)



Regulatory Compliance

BSMI, CE, FCC(Class A)



Dimensions

842.5mm x 449mm x 43.85mm (33.17" x 17.68" x 1.73")



Form Factor

1U



Weight

Net Weight : 18.85KG
Gross Weight : 23.89KG



Power Supply

1+1 Redundant 1200W/1600W 80 PLUS Platinum Power Supply
Rating: 100-127/200-240Vac,9.4A/4.72A (x2) ,50/60Hz Class I (240Vdc, 4.6A Only for China)

*1600W RPSU is required while choosing GPU SKU



Environment

Operation temperature: 10? ~ 35?
Non operation temperature: -40? ~ 60?
Non operation humidity: 20% ~ 90% (Non condensing)



Optional Items

Standard Cooling Solution or
Water Cooling Solution



Note

If only 1 CPU is installed, some functions might be not available.
*SAS support only from SAS HBA/RAID Card



CPU Heatsink/ Cooler

2



Fan

1 (For supporting GPU SKU, it will have external fan)
