Popis produktu

Processor / System Bus


1 x Socket LGA1200
Intel® Xeon® processor E-2300 family
Intel ®  Pentium™ processors
*Refer to support page for more information



Generation


E11



Core Logic


Intel® C252 Chipset



Memory


Total Slots :
4 (2-channel)
Capacity :
Maximum up to 128GB UDIMM
Memory Type :
DDR4 3200/2933/2666 UDIMM
Memory Size :
32GB, 16GB, 8GB, 4GB UDIMM
* Refer to support page for more information



Expansion Slots


Total PCI/PCI-X/PCI-E/PIKE Slots: 3 1 x PCI-E x 16 (Gen4 x16 Link, switch to x8 link when slot B occupied), FH/HL 1 x PCI-E x 8 (Gen4 x8 Link), HH/HL* 1 x PCI-E x 4 (Gen3 x4 Link), Proprietary R/A slot (optional for Intel X710 10G LAN card) * not available when supporting NVME SSD



Storage


Storage Controller :
Intel® C252 Chipset
6 x eSATA 150/300 MB/s ports
Intel ® VROC (For Linux/Windows)
(Support Software RAID 0/1/5/10 )
SAS Controller :
ASUS PIKE II 3008-8i 8-port SAS 12G RAID card
ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card



HDD Bays


4 x 3.5” Hot-Swap HDD Bays -up to (2*SATA/SAS/NVMe + 2*SATA/SAS) *SAS support only from optional SAS HBA/RAID card *NVMe support only from optional NVMe upgrade kit



Auxiliary Storage FDD/CD/DVD


1 x Slim-type Optical Drive Bay Options: No Device / DVD-RW / DVD-ROM



Networking


2 x Intel® I210AT + 1 x Mgmt LAN



Graphic


Aspeed AST2600 with 64MB VRAM



Multi-GPU Support


Please find the latest GPU support from  https://servers.asus.com/support/gpu



Front I/O Ports


1 x VGA port* 2 x USB 3.2 Gen1 ports *Must support by ASMB10



Rear I/O Ports


2 x USB 3.2 Gen 2 ports 1 x VGA port * 1 x HDMI port from CPU 1 x COM port 2 x RJ-45 ports 1 x RJ-45 ports (One for ASMB10-iKVM)(Optional) *Must support by ASMB10



Switch/LED


Rear Switch/LED: 1 x Q-Code/Port 80 LED 1 x Power switch Front Switch/LED: 1 x Power switch/LED 1 x Location switch/LED 1 x Reset switch 1 x HDD Access LED 1 x Message LED LAN 1-2 LED



OS Support


Please find the latest OS support from  https://servers.asus.com/support/os



Management Solution


ASUS Control Center Enterprise (Optional) Optional ASMB10-iKVM for KVM-over-Internet



Regulatory Compliance


BSMI, CE, FCC(Class A)



Dimensions


497mm x 439.5mm x 44mm



Power Supply


Single 350W 80 PLUS Gold Power Supply
Rating: 100-240Vac, 6.3-3A 60-50Hz, Class 1



Environment


Operating temperature: 10°C ~ 35°C Non operating temperature: -40°C ~ 70°C Non operating humidity: 20% ~ 90% ( Non condensing)
