Popis produktu








CPU
Platform
CPU
Scoket
CPU #
U
Max
CPU TDP
Chipset
Memory
Type
Memory
#
Storage
#
Storage
Bay
Storage
Type
NVMe grade
(option)
Storage
Hotswap
SAS
Controller
M.2
Other
Storage
ODD
O/B NIC
GPU
Sport
PCIe
#
PCIe slots
OCP
PSU
#
Railkit
PSU
Type
Heatsink
Type
Depth
(mm)


EPYC
Genoa
LGA6096
1
1U
240W
SOC
DDR5 4800
12
4
3.5"
SATA/SAS*/4xNVMe
-
Y
Option
2
0
0
Intel i350 1Gb x2
-
3
1 x PCIe x16 slot (Gen5 x16 link, FH, HL)  1 x PCIe x16 slot (Gen5 x16 link, LP, HL)
1 x PCIe x16 slot (Gen5 x8 link, LP, HL)
3.0X1
1+1
1000mm
Friction
800W 80+ Titanium
1U EVAC HS
842.5 x 449 X 43.85











Processor / System Bus


1 x Socket SP5 (LGA 6096)
AMD EPYC™ 9004 Series Processors (up to 400W)



Memory


24  x DIMM slots
DDR5 4800/4400 RDIMM/ 3DS RDIMM
Maximum 6144GB
*2DPC support depends on AMD schedule
* Refer to support page for more information



Expansion Slots


Up to 3 PCIe Gen5 slots + 1 OCP3.0
1 x PCIe x16 slot (Gen5 x16 link, FH, HL)
1 x PCIe x16 slot (Gen5 x16 link, LP, HL)
1 x PCIe x16 slot (Gen5 x8 link, LP, HL)
1 x OCP3.0 socket (Gen5 x16 link)



Storage


Storage Controller  :
CPU Integrated
Optional kits Controller  :
ASUS PIKE II 3008-8i 8-port SAS 12G HBA card



Drive Bays


Front bays:
4 x 2.5” Hot-swap Storage Bays
4 x SATA/SAS/NVME

*SAS support only from optional SAS
HBA/RAID card

2 x M.2 connectors



Networking


1 x Dual Port Intel I350-AM2 GbE LAN Controller
1 x Management Port



Graphic


Up to 2 single-slot GPU cards



Front I/O Ports


2 x USB 3.2 Gen1 ports
1 x VGA port



Rear I/O Ports


2 x USB 3.2 Gen1 ports
1 x VGA port
1 x Management port
2 x 1GbE LAN ports



Switch/LED


Front :
1 x Power Button/LED
1 x Location Button/LED
1 x Message LED
1 x HDD LED
4 x LAN LED (1-2 for on-board LAN, 3-4 for OCP LAN)
Rear :
1 x Port80 LED (Q-Code)
1 x Power Button/LED
1 x Location Button/LED
1 x Message LED



OS Support


Please find the latest OS support from  https://servers.asus.com/support/os



Management Solution


ASUS Control Center
ASUS ASMB11-iKVM (on-board)



Regulatory Compliance


BSMI, CB, CE, RCM, FCC(Class A)



Dimensions


842.5mm x 449mm x 43.85mm (1U)
33.17" x 17.68" x 1.73"



Form Factor


1U



Weight


(approximate)
Net Weight: 13.15 kg
Gross Weight: 18.15 kg



Power Supply


1+1 Redundant 1600W 80 PLUS Titanium
Power Supply
1+1 Redundant 1200W/800W 80 PLUS Platinum
Power Supply



Environment


Operating temperature: 10°C – 35°C
Non operating temperature: -40°C – 70°C
Non operating humidity: 20% – 90% (Non condensing)

Note
Operating Temperature based on configurations















Products certified by the Federal Communications Commission and Industry Canada will be distributed in the United States and Canada. Please visit the ASUS USA and ASUS Canada websites for information about locally available products.
All specifications are subject to change without notice. Please check with your supplier for exact offers. Products may not be available in all markets.
Specifications and features vary by model, and all images are illustrative. Please refer to specification pages for full details.
PCB color and bundled software versions are subject to change without notice.
Brand and product names mentioned are trademarks of their respective companies.
The terms HDMI and HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.



The information contained is general testing result for reference. Please consult local sales representative for more information on specific supported CPU list on each system.
* Optional means “built for order”.

---
